AWWA Non Rising Stem Gate Valve

From: 290.00 From: 188.33

From: 290.00 From: 188.33
Clear
Custom Enquiry

Description

AWWA Non Rising Stem Gate Valve

Size Range: 2″ to 72″

Temperature Range: Up to 120°C

Pressure Rating: PN10, PN16, PN25,PN40

Connections: Flange, Mechanical Joint, FLxMJ, Tapping

Body Material: Ductile Iron, Stainless Steel,Cast Iron,Cast Steel

Operating: gear box, electric actuator, Handwheel, Chainwheel

Seal Options: Resilient Wedge Seated, Metal Seated

Styles: None Rising Stem, Outside Stem and Yoke

Design and manufacture conform to AWWA, BS5163, DIN3352, DIN3202 F4/F5

Face to face dimensions conform to AWWA, BS5150& BS5163, DIN3202 F4/F5

Flange dimensions conform to EN1092-2 PN10/PN16, ANSI B16.5, B16.1, JIS10K

Testing conform to API598

Epoxy coating or Special coating for potable water

Operated by Handwheel operated (gear box be optional)

Main Material:

NO PART NAME METERIAL
1 BODY GRAY IRON, DUCTILE IRON
2 DISC GRAY IRON, DUCTILE IRON with EPDM, BUNA
3 DISC NUT GRAY IRON, DUCTILE IRON
4 NUT Q235A
5 BONNET GRAY IRON, DUCTILE IRON
6 STEM Q235A
7 SEAL RING NBR, EPDM
8 NUT BRASS
9 HAND WHEEL DI/C.S.
10 BOLT Q235A
11 SEAL RING NBR, EPDM
12 LOCATING RING Q235A

Dimension:

DN 50 65 80 100 125 150 200 250 300 350 400 450 500
2″ 2.5″ 3″ 4″ 5″ 6″ 8″ 10″ 12″ 14″ 16″ 18″ 20″
L 150 170 180 190 200 210 230 250 270 290 310 330 350
D 165 185 200 2200 250 285 340 405 460 505/520 565/580 615/640 670/715
D1 125 145 160 180 210 240 295 355 410 460/470 515/525 565/585 620/650
